- Measuring tip with TC connector type T
Measuring tip with TC connector type T
0628 0023
Measuring tip with TC connector type T
0628 0023Wiry measuring tip for fast measurement of temperatures in incoming goods
Ideal for measuring between the packages in frozen goods
The measuring tip with TC connector type T is ideal for measuring temperatures in incoming goods.
1 x measuring tip with TC connector type T.
Temperature - TC Type T (Cu-CuNi)
| Measuring range | -50 to +350 °C |
|---|---|
| Accuracy | ±0.5 °C (-40 to +133 °C) Class 1 Remaining Range |
| Reaction time | 5 s |
| 1) According to standard EN 60584-2, the accuracy of Class 1 and Class 2 refers to -40 to +350 °C (Type T). | |
General technical data
| Weight | 10 g |
|---|---|
| Dimensions | 530 mm |
| Diameter probe shaft | 1.5 mm |
| Product-/housing material | Stainless steel |
| Length probe shaft | 500 mm |
| Product colour | blue; silver |
| Measuring rate | 5 s |
- Incoming goods probe 0628 0023(pdf, 99.2 kB)
