Measuring range | -50 to +150 °C |
---|---|
Accuracy | ±0.5 °C |
Resolution | 0.1 °C |
Probe connection | 2 x Plug-in (NTC) |
Measuring range | -1 to 60 bar |
---|---|
Accuracy | ±0.25 % fs |
Resolution | 0.01 bar |
Probe connection | 3 x 7/16" – UNF + 1 x 5/8'' – UNF |
Overload rel. (low pressure) | 65 bar |
Overload rel. (high pressure) | 65 bar |
Weight | 1 kg |
---|---|
Dimensions | 229 x 112 x 71 mm |
Operating temperature | -20 to +50 °C |
Protection class | IP54 |
System requirements | requires iOS 11.0 or newer; requires Android 6.0 or newer; requires mobile end device with Bluetooth 4.0 |
Auto-off instrument | 10 min |
Battery life | With built-in rechargeable battery:; ≥220 h without Bluetooth®, without illumination; ≥120 h with Bluetooth® and illumination; With 3 AA batteries:; ≥145 h without Bluetooth®, without illumination; ≥75 h with Bluetooth® and illumination |
Battery type | Built-in rechargeable battery: LI batttery 18650; Replaceable battery: 3 alkaline batteries AA |
Radio range | 150 m |
Storage temperature | -20 to +60 °C |
Measuring range | -40 to +150 °C |
---|---|
Accuracy | ±1.3 °C (-20 to +85 °C) |
Resolution | 0.1 °C |
Weight | 127.4 g |
---|---|
Dimensions | 183 x 90 x 30 mm |
Operating temperature | -20 to +50 °C |
Product-/housing material | Plastic |
System requirements | requires iOS 13.0 or newer; requires Android 8.0 or newer; requires mobile end device with Bluetooth 4.0 |
Product colour | black/orange |
Battery life | 150 h |
Battery type | 3 AAA micro batteries |
Data transfer | Bluetooth® |
Radio range | 100 m |
Refrigerant | A2L / A3 compatibel |
Storage temperature | -20 to +60 °C |
Measuring range | 0 to 26.66 mbar / 0 to 20000 micron |
---|---|
Accuracy | ±(1 ±10 micron + 10 % of mv (100 to 1000 micron) |
Resolution | 100 micron (2000 to 5000 micron) / 1 micron (0 to 1000 micron) / 10 micron (1000 to 2000 micron) / |
Overload | absolute: 6.0 bar / 87 psi (relative: 5.0 bar / 72 psi) |
Weight | 142 g |
---|---|
Dimensions | 150 x 32 x 31 mm (LxWxH) |
Operating temperature | -10 to +50 °C |
Protection class | IP54 |
System requirements | requires iOS 13.0 or newer; requires Android 8.0 or newer; requires mobile end device with Bluetooth 4.2 |
Product colour | black/orange |
Auto-off | 10 min* |
Battery type | 3 AAA micro batteries |
Battery life | 39 h |
Connection | 7/16“ UNF |
Interface | Bluetooth® 4.2 |
Storage temperature | -20 to +50 °C |
* when not connected via Bluetooth |
Measuring range | -20 to +500 °C |
---|---|
Accuracy | ±1 °C (0 to +100 °C) |
Resolution | 0.2 °C |
Measuring range | 1.0 to 600.0 V |
---|---|
Resolution | max. 1 mV |
Accuracy | ± (0.8 % of mv + 3 Digit) |
Measuring range | 1.0 mV to 1000.0 V |
---|---|
Resolution | max. 1 mV |
Accuracy | ± (1 % of mv + 3 Digit) |
Measuring range | 0.01 to 600.0 A (clamp) 0.1 to 600.0 μA (measuring cables) |
---|---|
Resolution | 0.1 (clamp) 0.1 (measuring cables) |
Accuracy | ± (2 % of mv + 5 Digit) (measuring cables) ± (2 % of mv + 5 Digit) (clamp) |
Measuring range | 0.01 to 600.0 A (clamp) 0.1 to 600.0 μA (measuring cables) |
---|---|
Resolution | 0.01 A (clamp) 0.1 μA (measuring cables) |
Accuracy | ± (2 % of mv + 5 Digit) (clamp) ± (1.5 % of mv + 5 Digit) (measuring cables) |
Resolution | max. 0.01 Ohm |
---|---|
Measuring range | 0.10 to 60.0 MOhm |
Accuracy | ± (1.5 % of mv + 3 Digit) |
Resolution | max. 0.01 nF |
---|---|
Measuring range | 0.001 μF to 60000.00 μF |
Accuracy | ± (1.5 % of mv + 5 Digit) |
Resolution | max. 0.1 Hz |
---|---|
Measuring range | 0.00 Hz to -10 kHz |
Accuracy | ± (1 % of mv + 1 Digit) |
Measuring range | 0.1 W to 600 kW |
---|---|
Accuracy | ± (5 % of mv + 5 Digit) |
Resolution | 0.1 W |
Measuring range | 0.1 to 600.0 kvar |
---|---|
Accuracy | ± (10 % of mv + 5 Digit) |
Resolution | 0.1 var |
Measuring range | 0.1 VA to 600.0 kVA |
---|---|
Accuracy | ± 1 Digit |
Resolution | 0.1 VA |
Measuring range | 0.1 W to 600.0 kW |
---|---|
Accuracy | ± 1 Digit |
Resolution | max. 0.1 W |
Measuring range | -1.00 to +1.00 |
---|---|
Accuracy | ± (10 % of mv + 5 Digit) |
Resolution | 0.01 |
Operating humidity | 0 to 80.0 %RH |
---|---|
Weight | 378 g |
Dimensions | 249 x 96 x 43 mm |
Operating temperature | -10 to +50 °C |
Connectable probes | 1 x temperature probe (adapter required for type K thermocouples) |
Product colour | Black |
System requirements | requires iOS 11.0 or newer; requires Android 6.0 or newer; requires mobile end device with Bluetooth 4.0 |
Standards | EN 61326-1; EN 61010-2-032; EN 61140 |
Battery type | 3 AAA micro batteries |
Display size | 2 lines |
Display type | LCD (Liquid Crystal Display) |
Interface | 2 measuring jacks |
Storage temperature | -15 to +60 °C |
Overvoltage Category | CAT IV 600V; CAT III 1000V |
Authorizations | CSA; CE |
Internal_resistance | 11 MOhm (AC / DC) |
Diode test | yes |
---|---|
Continuity testing | yes |
Display ligthing | yes |
Hold | yes |
MinMax | yes |
Power Measurement | yes |
Temperature measurement with adapter | yes |
True RMS | yes |
Inrush current measurement | yes |
Bluetooth | yes |
Display (counts) | 6,000 |
Autom. measurement parameter detection | yes |
μA current measuring range | yes |
Weight | 1200 g |
---|---|
Dimensions | 455 x 320 x 108 mm |
Product colour | Black |
