testo Saveris 2-T2 - WiFi data logger with display and 2 connections for NTC temperature probes

제품 번호  0572 2032

  • 연결 가능한 센서(옵션)를 사용한 자동화 온도 모니터링

  • 설치와 사용법이 간단한 무선 온도 측정 시스템

  • 스마트폰, 태블릿이나 PC를 통하여 측정 데이터를 언제든지 호출하고 평가

  • 한계치 초과시 이메일 또는 문자 메시지(옵션)를 통하여 경고 알림

The WiFi data logger testo Saveris 2-T2 allows you to monitor the temperatures and door contacts in refrigerated and work- or storerooms. The temperature values and door contacts measured with the connectable probes are reliably recorded over long periods, and transmitted directly to the Testo Cloud (online data store) via your WiFi. You can access these readings at any time, anywhere, using your internet-enabled smartphone, tablet or PC.

이 제품은 프로브를 필요로 하는 제품입니다.

여기를 누르시면 프로브 리스트를 확인하실 수 있습니다.

제품 설명

The testo Saveris 2 WiFi data logger system is the easy, versatile and reliable solution for the measurement and monitoring of temperature and door contact values in your storage, refrigerated and work rooms. Installing the system is child's play and can be carried out via a browser.



Temperature monitoring with testo Saveris 2


The temperature monitoring system consists of at least one WiFi data logger and a Cloud access (online data store). As a component of this data logger system, the testo Saveris 2-T2 data logger with up to 2 connectable NTC temperature probes or door contacts stores all measured temperature values and door contacts and transmits them directly by wireless LAN to the Testo Cloud. You can use the alarm function to receive immediate warnings by e-mail or SMS (optional) when limit values are violated.



The Testo Cloud packages: Basic (free) and Advanced


The Testo Cloud is the core operating element for setting up your testo Saveris 2 system. Here you can configure your WiFi data loggers, set limit value alarms and analyze your measurement data. You can access all measuring values and analysis functions anywhere and at any time with an internet-capable smartphone, tablet or PC. You must first register at www.saveris.net to have access to the Testo Cloud.

Depending on the range of functions you require, you have a choice between the free Basic and the more extensive Advanced functionality for use of the Testo Cloud:

  Basic (free) Advanced
Measuring cycle 15 min. ... 24 h 1 min. ... 24 h
Communication cycle 15 min. ... 24 h 1 min. ... 24 h
Data storage Max. 3 months Max. 2 years
Reports Manual (.pdf/.csv) Manual (.pdf/.csv)
Automatic (.pdf/.csv)
Number of users per account 1 10
Number of WiFi data loggers
per account
Unlimited Unlimited
Alarm options Upper/lower alarm limits • Upper/lower alarm limits
• Alarm delay
• Time control of alarms
System notifications • Notification of low battery
• Radio link interrupted
• Power supply interrupted
• Notification of low battery
• Radio link interrupted
• Power supply interrupted
E-mail alarm Yes Yes
SMS alarm No • Including 25 SMS per logger and year
• Option of purchasing additional SMS packages
Measurement data export (API interface) No Yes

If you opt for the advantages of the Advanced package, this also gives you a choice between licence packages which differ in terms of their validity period (12-month licence with order no. 0526 0735, 24-month licence with order no. 0526 0732 and 36-month licence with order no. 0526 0733).




WiFi data logger: advantages and functions


Current measuring values, limit value violations and the remaining battery life can be seen in the data logger's display. The standard batteries (AA) have a lifetime of 12 months and can be replaced at any time by users themselves. The internal data memory of the WiFi data logger is 2 x 10,000 readings and the housing has IP65 protection. The testo Saveris 2-T2 is tested by TÜV Süd according to EN 12830.

Hint:
In order to use the testo Saveris 2-T2 WiFi data logger, you also require at least one connectable probe (optional).





상품 제공 시 포함

  • testo Saveris 2-T2 WiFi data logger
  • Including free Cloud access (basic functionality)
  • Micro USB cable
  • Wall bracket with lock
  • Batteries (4 x AA AlMn Mignon batteries)
  • Short instructions
  • Calibration protocol

Hint:

In order to use the testo Saveris 2-T2 WiFi data logger, you also require at least one connectable probe (optional).


기술 데이터

무게

240 g

크기

95 x 75 x 30.5 mm

작동 온도

-30 ~ +50 °C

보호등급

IP65

측정 비율

클라우드 시스템에 따라 다름; Basic : 15분~ 24시간/ Advanced : 1분~ 24시간

Door contact

가능

통신 속도

클라우드 시스템에 따라 다름; Basic : 15분~ 24시간/ Advanced : 1분~ 24시간

WLAN연결

2.4 GHz 주파수대 신호 무선 전송; WEP, WPA, WPA2, WPA2 를 사용하지 않는 암호화 벙법, 데이터 로거는 표준 프로토콜 MQTT를 통해 통신하며 SNTP 시간 동기화가 가능합니다.

표준렌즈

DIN EN 12830

외부 연결

External temperature probes

전력 공급

4 x AA AlMn batteries; mains unit optional; for temperatures below -10 °C please use Energizer batteries 0515 0572

메모리

10,000 measurement values / channel

보관 배터리 수명

12 months (typical value, depending on the wireless LAN infrastructure) at +25 °C, 15-minute measuring cycle and standard communication cycle at -30 °C, 15-minute measuring cycle and standard communication cycle with Energizer batteries 0515 0572

보관 온도

-40 ~ +70 °C (배터리 미포함)

NTC

NTC 센서 측정 범위

-50 ~ +150 °C

NTC 센서 정확도

±0.3 °C

NTC 센서 분해능

0.1 °C
