Compacte rookgassonde, lengte 180 mm, Ø 6 mm, Tmax. 500°C

0600 9740
€ 165,00 € 199,65
1
  • Flue gas path and temperature channel can be connected to the instrument via a bayonet lock
  • Integrated dirt filter protects instrument and sensors
  • Integrated thermocouple probe for temperature measurements up to 500 °C
  • Includes practical cone for attachment
  • Compacte rookgassonde, lengte 180 mm, Ø 6 mm, Tmax. 500°C
    The compact basic flue gas probe is equipped with a dirt filter, which protects the measuring instrument and its sensors. Flue gas path and temperature channel can conveniently be connected to the measuring instrument via a practical bayonet lock. The thermocouple NiCr-Ni, which is integrated in the 180 mm long probe shaft, enables temperature measurement up to 500 °C.

    Compact basic flue gas probe 180 mm including dirt filter, cone for attachment, thermocouple NiCr-Ni Tmax 500 °C and hose 1.5 m.

    Algemene technische gegevens

    diameter pitotbuis
    6 mm
    kabellengte
    1,5 m
    lengte voerlerbuis
    180 mm
    productkleur
    Zwart
    max. temperatuur
    500 °C
    diameter
    6 mm
    Gewicht
    346 g

    Accessoires

  • Accessoires
    Spare particle filter
    Reservefilters voor CO-verbrandingssonde (10 stuks)
      :
      0554 0040
      € 29,00 € 35,09
      1
    • Accessoires
      Conus met vergrendelingsschroef
        :
        0554 9010
        € 22,00 € 26,62
      • Accessoires
        No picture available
        Conus 6 mm, PTFE, met veerklem en grijpmogelijkheid, Tmax 200 °C
          :
          0554 3327
          € 37,00 € 44,77
