Compacte rookgassonde, lengte 180 mm, Ø 6 mm, Tmax. 500°C

Bestelnr.  0600 9740

€ 162,00
inclusief btw, Bebat en Recupel € 196,02
  • Flue gas path and temperature channel can be connected to the instrument via a bayonet lock

  • Integrated dirt filter protects instrument and sensors

  • Integrated thermocouple probe for temperature measurements up to 500 °C

  • Includes practical cone for attachment

Compacte rookgassonde, lengte 180 mm, Ø 6 mm, Tmax. 500°C


Details

Productbeschrijving

The compact basic flue gas probe is equipped with a dirt filter, which protects the measuring instrument and its sensors. Flue gas path and temperature channel can conveniently be connected to the measuring instrument via a practical bayonet lock. The thermocouple NiCr-Ni, which is integrated in the 180 mm long probe shaft, enables temperature measurement up to 500 °C.

Leveringsomvang

Compact basic flue gas probe 180 mm including dirt filter, cone for attachment, thermocouple NiCr-Ni Tmax 500 °C and hose 1.5 m.

Gerelateerde producten


Technische gegevens

Algemene technische gegevens

diameter pitotbuis

6 mm

kabellengte

1,5 m

lengte voerlerbuis

180 mm

productkleur

Zwart

max. temperatuur

500 °C

diameter

6 mm

Gewicht

346 g


Toebehoren

Accessoires

€ 28,00
inclusief btw, Bebat en Recupel  € 33,88
Conus met vergrendelingsschroef

Artikelnummer 0554 9010

€ 22,00
inclusief btw, Bebat en Recupel  € 26,62
€ 37,00
inclusief btw, Bebat en Recupel  € 44,77
€ 162,00
inclusief btw, Bebat en Recupel € 196,02
Gratis verzending
