Modulaire rookgassonde lengte 300 mm, Ø 8 mm, Tmax 500 °C, T...

Artikelnummer  0600 9761

  • Easy probe shaft replacement via quick-change click system

  • Flue gas path and temperature channel can be connected to the instrument via a bayonet lock

  • Integrated dirt filter protects instrument and sensors

  • Integrated thermocouple probe for temperature measurements up to 500 °C

Modulaire rookgassonde lengte 300 mm, Ø 8 mm, Tmax 500 °C, TÜV-getest

Productomschrijving

The TÜV-tested modular flue gas probe with 300 mm long probe shaft features a quick-change click system on the handle, which enables easy replacement of the probe shaft. The thermocouple NiCr-Ni, which is integrated in the probe shaft, enables temperature measurement up to 500 °C. Flue gas path and temperature channel can be conveniently connected to the measuring instrument via a practical bayonet lock. In addition, a dirt filter protects the instrument and its sensors from contamination.



Wat wordt er geleverd?

Modular flue gas probe 300 mm including dirt filter, cone for attachment, thermocouple NiCr-Ni Tmax 500 °C and hose 2.2 m.
Algemene technische gegevens

lengte voerlerbuis

300 mm

kabellengte

2,2

diameter

6 mm

max. temperatuur

500 °C

Accessoires

Reservefilters (10 stuks)

Artikelnummer: 0554 3385

21,00 €
25,41 € incl. BTW
