Compacte rookgassonde, lengte 180 mm, Ø 6 mm, Tmax. 500°C

Bestelnr.  0600 9740

  • Flue gas path and temperature channel can be connected to the instrument via a bayonet lock

  • Integrated dirt filter protects instrument and sensors

  • Integrated thermocouple probe for temperature measurements up to 500 °C

  • Includes practical cone for attachment

Compacte rookgassonde, lengte 180 mm, Ø 6 mm, Tmax. 500°C

Levertijd 3 tot 6 werkdagen

Verzendkosten opmerking

€ 169,00
€ 204,49 inclusief btw

Productbeschrijving

The compact basic flue gas probe is equipped with a dirt filter, which protects the measuring instrument and its sensors. Flue gas path and temperature channel can conveniently be connected to the measuring instrument via a practical bayonet lock. The thermocouple NiCr-Ni, which is integrated in the 180 mm long probe shaft, enables temperature measurement up to 500 °C.



Leveringsomvang

Compacte rookgassonde, lengte 180 mm, Ø 6 mm, Tmax. 500°C
Algemene technische gegevens

lengte voerlerbuis

300 mm

kabellengte

1,5 m

diameter

6 mm

max. temperatuur

500 °C

Accessoires

€ 27,00
€ 32,67 inclusief btw
Conus met vergrendelingsschroef

Artikelnummer 0554 9010

€ 22,00
€ 26,62 inclusief btw
€ 35,00
€ 42,35 inclusief btw
