Compact basic flue gas probe, 300 mm, Ø 6 mm, Tmax 500 °C

Order-Nr.  0600 9741

€ 184,80
z DDV-om € 225,46
  • Flue gas path, draught path and temperature probe can be connected via a single probe coupling

  • Easy-to-replace dirt filter

  • Temperatures of up to 500 °C can be measured thanks to the thermocouple probe

  • Includes practical cone for attachment

Compact flue gas probe with 300 mm long probe shaft including particle filter and thermocouple. Bayonet lock ensures quick, easy connection to the measuring instrument.


Product Description

The compact flue gas probe can be connected to the flue gas analyzer quickly and easily. Thanks to its bayonet lock, the flue gas path, draught path and temperature probe can be connected to the measuring instrument via a single probe coupling. On the probe handle there is a particle filter, which protects the gas paths of the measuring instrument from contamination and which can also be replaced easily without any tools. The flue gas probe measures temperatures of up to 500 °C and its immersion depth of 300 mm also makes it suitable for carrying out measurements on large combustion plants.

Delivery Scope

Compact basic flue gas probe 300 mm including dirt filter, cone for attachment, thermocouple NiCr-Ni Tmax 500 °C and hose 1.5 m.

Podobni izdelki

Technical Data

General technical data

Diameter probe shaft

6 mm

Cable length

1,5 m

Length probe shaft

300 mm

Product colour


Temperature maximum

500 °C


6 mm


364 g




€ 30,00
z DDV-om  € 36,60
Cone with fixing screw

Order Number: 0554 9010

€ 184,80
z DDV-om € 225,46
