Compact basic flue gas probe - 300 mm, Ø 6 mm, Tmax 500 °C
0600 9741Compact basic flue gas probe - 300 mm, Ø 6 mm, Tmax 500 °C
0600 9741Flue gas path, draught path and temperature probe can be connected via a single probe coupling
Easy-to-replace dirt filter
Temperatures of up to 500 °C can be measured thanks to the thermocouple probe
Includes practical cone for attachment
Compact flue gas probe with 300 mm long probe shaft including particle filter and thermocouple. Bayonet lock ensures quick, easy connection to the measuring instrument.
Compact basic flue gas probe 300 mm including dirt filter, cone for attachment, thermocouple NiCr-Ni Tmax 500 °C and hose 1.5 m.
General technical data
| Diameter probe shaft | 6 mm |
|---|---|
| Cable length | 1,5 m |
| Length probe shaft | 300 mm |
| Product colour | Black |
| Temperature maximum | 500 °C |
| Diameter | 6 mm |
| Weight | 364 g |
| | |
