testo 110 - NTC in Pt100 merilni instrument za merjenje temperature s povezavo APP

0563 0110
€ 126,00 € 153,72
  • Preprosta, hitra in posebej natančna meritev temperature s Sonde NTC ali Pt100 (opcijsko na voljo)
  • Konfiguracija v aplikaciji, zgodovina grafov, drugi zaslon in pomnilnik merilnih podatkov v aplikaciji testo Smart
  • S HACCP, certificiran po EN 13485 za uporabo v živilskem sektorju
  • Natančni merilni rezultati in izjemna sistemska natančnost z digitalnimi senzorji Pt100 (umerjanje brez merilnega instrumenta)
    • Kompaktni merilni instrument za merjenje temperature Testo 110 pokaže svoje prednosti povsod, kjer je treba opraviti meritve pri zelo nizkih temperaturah ali kjer je treba določiti zelo natančne temperature. Skladnost s HACCP in združljivost z NTC ali PT100 (sonda je na voljo po izbiri) naredi testo 110 idealnega za merjenje temperature, zlasti v prehranskih okoljih ali laboratorijih.

    Enostaven za uporabo in natančen pri merjenju: Na ta način je kompaktni instrument za merjenje temperature Testo 110 prepričljiv pri vsakodnevni uporabi. Hitra vsestranska naprava za merjenje temperature lahko pokaže svoje prednosti zlasti pri uporabi v laboratorijih ali v prehrambenem okolju: Opcijsko razpoložljivi sondi NTC ali Pt100 pokrivata celovit sklop merilnih nalog in zagotavljata točne rezultate s posebno visoko natančnostjo. Digitalne sonde Pt100 je mogoče umeriti tudi brez merilnega instrumenta - tako da lahko preprosto nadaljujete delo z drugo sondo brez izpadov.

    • Konfiguracija testo 110
    • Drugu zaslon
    • Pomnilnik merilnih podatkov
    • Prikaz izmerjenih vrednosti (tabela, grafikon)
    • Dokumentacija

    • testo 110 - 1-kanalni instrumenti za merjenje temperature NTC / Pt100 s povezavo APP, nastavek za sondo in zvočni alarm
    • Transportni etui
    • Kalibracijski protokol
    • 3 x AA baterije

    Temperature - Pt100

    Measuring range
    −200 to +800 °C
    Accuracy
    according to the probe accuracy
    Resolution
    according to the probe accuracy

    Temperature - NTC

    Measuring range
    −50 to +150 °C
    Accuracy
    ±0,3 °C (Remaining Range)
    ±0,2 °C (−20,0 to +80,0 °C)
    Resolution
    0,1 °C

    General technical data

    Weight
    187,0 g
    Dimensions
    135 x 60 x 28 mm
    Operating temperature
    −20 to +50 °C
    Product-/housing material
    ABS + PC / TPE
    Protection class
    IP40; IP65 with TopSafe
    Battery life
    100h
    Battery type
    3x AA
    Storage temperature
    −20 to +50 °C

    Temperature probes

  • Temperature probes
    High-precision immersion/penetration probe (digital)
    High-precision immersion/penetration probe (Pt100 temperature sensor, digital) for temperature measurements in liquids and pastes – measuring range -80 to +300 °C, accuracy up to ±0.05 °C
      :
      0618 0275
      € 483,00 € 589,26
    • Temperature probes
      Immersion/penetration probe (digital)
      Immersion/penetration probe (digital) with Pt100 temperature sensor: for temperature measurements in liquids and pastes – measuring range -100 to +400 °C, accuracy up to ±0.15 °C
        :
        0618 0073
        € 243,00 € 296,46
      • Temperature probes
        Glass-coated laboratory probe (digital)
        Glass-coated laboratory probe (Pt100 temperature sensor, digital) for temperature measurements in aggressive media – measuring range -50 to +400 °C
          :
          0618 7072
          € 243,00 € 296,46
        • Temperature probes
          Robust, fast-action air probe (digital)
          Robust, fast-action air probe (digital)
            :
            0618 0072
            € 243,00 € 296,46
          • Temperature probes
            Flexible temperature probe (digital)
            Flexible temperature probe (digital) with Pt100 temperature sensor: for temperature measurements in locations that are difficult to access and in liquids – measuring range -100 to +260 °C
              :
              0618 0071
              € 507,00 € 618,54
            • Temperature probes
              testo temperature probe
              Temperature cable probe (digital, with Pt100 temperature sensor)
                :
                0572 2163
              • Temperature probes
                testo temperature probe
                Stub temperature probe (digital, with NTC temperature sensor)
                  :
                  0572 2162
                • Temperature probes
                  Pipe wrap probe with NTC temperature sensor for measurements on pipes (Ø 5-65 mm)
                  Pipe wrap probe (NTC temperature sensor) for measuring the surface temperature of pipes (Ø 5-65 mm) – measuring range -60 to +130 °C
                    :
                    0615 5605
                    € 195,00 € 237,90
                  • Temperature probes
                    Temperature probe with Velcro and NTC temperature sensor
                    Temperature probe with Velcro (NTC temperature sensor) for measuring the surface temperature of pipes – measuring range -50 to +70 °C
                      :
                      0615 4611
                      € 99,00 € 120,78
                    • Temperature probes
                      Waterproof immersion/penetration probe with NTC temperature sensor
                      Waterproof immersion/penetration probe (NTC temperature sensor) for temperature measurements in liquids and semi-solid media – measuring range -50 to +150 °C, accuracy ±0.2 °C (-25 to +74.9 °C)
                        :
                        0615 1212
                        € 79,00 € 96,38
                      • Temperature probes
                        Robust air probe with NTC temperature sensor
                        Robust air probe (NTC temperature sensor) with a short response time, for measuring air temperature – measuring range -50 to +125 °C, accuracy ±0.2 °C (-25 to +80 °C)
                          :
                          0615 1712
                          € 81,00 € 98,82
                        • Temperature probes
                          Clamp probe with NTC temperature sensor for measurements on pipes (Ø 6-35 mm)
                          Clamp probe (NTC temperature sensor) for measuring the surface temperature of pipes (Ø 6-35 mm) – measuring range -40 to +125 °C
                            :
                            0615 5505
                            € 54,00 € 65,88
