Surface probe with widened measuring tip (TC type K)

Order-Nr.  0602 1993

  • Extra-wide measuring tip for flat surfaces

  • Thermocouple type K

  • Waterproof and robust (sturdy probe shaft)

  • Measuring range: -60 to +400 °C

Waterproof, robust and versatile: this temperature probe with sturdy probe shaft and widened measuring tip is ideal for measuring the temperature on flat surfaces.

Product Description

The waterproof surface temperature probe (thermocouple type K) can be used with many different measuring instruments. It can be used in a variety of ways for surface temperature measurements in industry or trade.



Delivery Scope

1 x waterproof surface temperature probe with wider measuring tip (TC type K), including fixed cable.
General technical data

Weight

114 g

Dimensions

length: 255 mm

Length probe shaft tip

52 mm

Diameter probe shaft

5 mm

Diameter probe shaft tip

6 mm

Cable length

1.16 m

Waterproof

Waterproof surface probe with widened measurement tip for flat surfaces, T/C Type K

Length probe shaft

115 mm

Product colour

grey

Interface

plug thermocouple

Temperature - TC Type K (NiCr-Ni)

Measuring range

-60 to +400 °C

Accuracy

Class 2 ¹⁾

Reaction time

30 s

1) According to standard EN 60584-2, the accuracy of Class 2 refers to -40 to +1200 °C.
