Surface probe with a small measuring head (TC type K)

Order-Nr.  0602 0693

  • Low-mass probe: very short response time for accurate measurement results

  • Thermocouple type K

  • Waterproof

  • Very large measuring range: -60 °C to +1000 °C

Accurate, waterproof and versatile: the temperature probe measures surface temperatures of up to 1000 °C. Its small measuring head is ideal for carrying out measurements on flat surfaces. Short response time.

Product Description

The surface temperature probe (thermocouple type K) can be used in a variety of applications in trade and industry. It can be connected to many different measuring instruments. It is also waterproof. This low-mass temperature probe is impressive thanks to its short response time.



Delivery Scope

Waterproof surface temperature probe with a small measuring head (TC type K) including fixed cable 1.2 m.
Temperature - TC Type K (NiCr-Ni)

Measuring range

-60 to +1000 °C

Accuracy

Class 1 ¹⁾

Reaction time

20 s

1) According to standard EN 60584-2, the accuracy of Class 1 refers to -40 to +1000 °C (Type K)

General technical data

Length probe shaft

150 mm

Cable length

1.2 m

Diameter probe shaft tip

4 mm

Diameter probe shaft

2.5 mm
