  2. Measuring tip with TC connector type T
0628 0023

Measuring tip with TC connector type T

0628-0023
This measuring tip with TC connector type T is designed for fast and accurate temperature measurements, particularly suitable for incoming goods inspections. Featuring a TC Type T sensor, it offers a measuring range of -50 to +350 °C with a rapid response time of 5 seconds. The stainless steel shaft, measuring 500 mm in length and 1.5 mm in diameter, ensures durability and precision. Its design makes it ideal for measuring temperatures between packages in frozen goods, providing reliable data for quality control processes.
  • TC Type T Sensor – Ensures precise temperature measurements.
    • Wide Measuring Range – From -50 to +350 °C for versatile applications.
  • Rapid Response Time – 5 seconds for quick readings.
  • Durable Construction – Stainless steel shaft with 1.5 mm diameter.
  • Extended Probe Length – 500 mm shaft for deep insertion.
The measuring tip with TC connector type T is engineered for professionals requiring swift and precise temperature assessments, especially in the context of incoming goods and frozen product inspections. Its TC Type T sensor delivers accurate readings across a temperature range of -50 to +350 °C, with an accuracy of ±0.5 °C between -40 and +133 °C, adhering to EN 60584-2 Class 1 standards. The probe's rapid response time of 5 seconds ensures timely data collection, crucial for maintaining the cold chain and ensuring product quality. Constructed with a robust stainless steel shaft measuring 500 mm in length and 1.5 mm in diameter, it offers both durability and the ability to reach deep into packages. Weighing just 10 g, the probe is lightweight and easy to handle, making it a practical tool for logistics, food safety inspections, and quality assurance tasks.

Temperature - TC Type T (Cu-CuNi)

Measuring range
-50 to +350 °C
Accuracy
±0.5 °C (-40 to +133 °C)
Class 1 Remaining Range
Reaction time
5 s
1) According to standard EN 60584-2, the accuracy of Class 1 and Class 2 refers to -40 to +350 °C (Type T).

General technical data

Weight
10 g
Dimensions
530 mm
Diameter probe shaft
1.5 mm
Product-/housing material
Stainless steel
Length probe shaft
500 mm
Product colour
blue; silver
Measuring rate
5 s
1 x measuring tip with TC connector type T.
