Robust air temperature probe (TC type K)

Order-Nr.  0602 1793

  • Thermocouple type K

  • Short response time thanks to the exposed sensor

  • Can be connected to a wide range of measuring instruments

  • Measuring range: -60 to +400 °C

Use the robust air temperature probe with exposed sensor (thermocouple type K) to measure air temperature with a short response time. It can be connected to a wide range of measuring instruments.

Product Description

Fast, robust and easy to use: simply hold the air temperature probe in the environment being measured – and, thanks to the exposed sensor in the probe shaft, you will obtain the air temperature value after only a short response time. The measurement result can be optimized by moving the probe through the air at approx. 1.5 m/s.



Delivery Scope

Robust air temperature probe (TC type K) with fixed cable 1.2 m.
Temperature - TC Type K (NiCr-Ni)

Measuring range

-60 to +400 °C

Accuracy

Class 2 ¹⁾

Reaction time

200 s

1) According to standard EN 60584-2, the accuracy of Class 2 refers to -40 to +1200 °C.

General technical data

Length probe shaft

115 mm

Cable length

1.2 m

Diameter probe shaft

4 mm
