testo 905-T2 - Surface probe

Order-Nr. 0560 9056

$ 139.50

excl. tax

Where to buy

Free Shipping December*

Delivery time: 1 working days

1-484-727-8381

Inquiry

Sprung thermocouple cross-band adapts to any surface
Very fast reaction time
Easy readout of readings due to rotatable display
Convenient reading of measurement results on the swivel display

The testo 905-T2 surface thermometer can measure the temperature reliably and impressively fast, even on uneven surfaces. Its measuring head with sprung thermocouple strip is what makes this possible. This efficient temperature measuring instrument is therefore suitable for diverse applications in the heating, plumbing, and refrigeration trade (like measurements on pipes or valves).

Details

Product Description

The testo 905-T2 surface thermometer provides you with the best piece of equipment for dealing with temperature measurements on both smooth and uneven surfaces. This is because its temperature probe (type K thermocouple) features a measuring head with sprung thermocouple strip that adjusts to the surface. This method prevents the temperature probe from tilting – and therefore providing false measurement results.
Another advantage of the temperature probe (type K thermocouple) is that its sprung thermocouple strip takes on the temperature of the object being measured very quickly. This temperature measuring instrument consequently achieves great accuracy and an impressively fast response time.
The testo 905-T2 surface thermometer also impresses with its large measuring range of -50 to +350 °C. Measurements of up to +500 °C are also possible for a short period (1 to 2 minutes). Its large measuring range means that the temperature measuring instrument has many different uses, like in the area of heating, plumbing, or refrigeration technology. This surface thermometer is particularly well suited to temperature measurements on pipes, as its thermocouple probe is easily able to deal with their uneven surfaces.

Extremely user-friendly surface thermometer

The testo 905-T2 surface thermometer is really easy to use; the measured values can be conveniently read from the clear display. They are also easily legible from different angles. This is provided for by the display's swivel joint, which can be constantly adjusted to your angle of vision.
If you forget to switch off the surface thermometer after measurement, it will automatically switch off after approx. 10 minutes of non-use.

Delivery Scope

testo 905-T2 surface thermometer with large measuring range, including attachment clip and batteries

Technical Data

Temperature
Measuring range	-58° to 662 °F (short-term to 932 °F) / -50 to +350 °C (short-term to +500 °C)
Accuracy	±(2 °F ±1 % of mv) / ±(1 °C ±1 % of mv)
Resolution	0.1 °F / 0.1 °C
Reaction time	t99 = 5 sec

General technical data
Weight	3 oz. / 80 g
Dimensions	8.7 x 1.6 x 2.8 in. ((LxWxH)) / 220 x 40 x 70 mm ((LxWxH))
Operating temperature	32° to 104 °F / 0 to +40 °C
Housing	ABS
Product colour	Black
Authorizations	CE 2004/108/EWG
Length probe shaft	5.906 in. / 150 mm
Length probe shaft tip	1.575 in. / 40 mm
Diameter probe shaft	0.118 in. / 3 mm
Diameter probe shaft tip	0.472 in. / 12 mm
Battery type	3 x AAA
Battery life	1000 h
Display type	LCD
Display size	one-line
Storage temperature	-4° to 158 °F / -20 to +70 °C

Downloads

Product Brochures

Data sheet testo 905 (PDF, 1055 kB)

Manuals

Short manual testo 905-T2 (PDF, 156 kB)
