testo 420 - volume flow hood/ balometer

0563 4200
ZAR 59,243.25 ZAR 68,129.74
1
  • Volume flow hood for larger swirl outlets for measuring volume flow, temperature and relative humidity
  • Impressively light with a weight of 2.9 kg
  • Precise measurement even at swirl outlets thanks to integrated volume flow straightener
  • Fast set-up, convenient usability and practical functions such as measurement data management and on-site report creation via testo Smart App
  • Make sure you get the testo 420 balometer/ volume flow hood for larger ceiling outlets and at the same time enjoy multiple maintenance benefits on HVAC systems. Because the flow hood with the removable measuring instrument is not only exceptionally light, it also guarantees accurate volume flow calculations at swirl outlets
    • testo-420-V25-EN-2000x1500.jpg

      Volume flow hood weighing less than 2.9 kg

    The testo 420 volume flow hood for larger air inlets and outlets enables fast and precise compliance with hygiene guidelines and requirements concerning indoor air quality. It provides reliable support with the calculation of the overall volume flow on HVAC systems, for instance in hospitals, office buildings or commercial buildings.

    High measuring accuracy at swirl outlets thanks to volume flow straightener

    Volume flow is frequently measured at swirl outlets. Air flows are often incorrectly measured due to the turbulent air at these outlets.

    With the volume flow hood testo 420, these measurement errors can be significantly reduced. The integrated volume flow straightener calms the turbulence and converts it into a virtually uniform air flow. This enables accurate calculation of volume flow in the 80 to 3,500 m3/h range.

    Exceptionally light volume flow hood with fast set-up

    The volume flow hood with ergonomic handles and tiltable display has an exceptional weight of less than 2.9 kg. This means that frequent volume flow calculations in large rooms and measurements above head height can also be carried out reliably and comfortably. In the process, a large measuring button on the volume flow hood ensures easy recording of the readings.

    The dimensions of the hood are 610 x 610 mm. We offer additional hoods as accessories for further ceiling outlets. The use of our optional tripod arm is a great help for air inlets and outlets which are located very high up. It can be extended up to 3.3 metres.

    Tension rods enable quick, easy set-up of the volume flow hood. The trolley which is included in the scope of delivery ensures safe transport.

    Create protocols directly on site and mail them using the App connection

    Take advantage of additional practical functions and download our free testo Smart App. The App connection enables mobile devices such as smartphones and tablets to be used via Bluetooth as a secondary display, for customer and measurement data management and as a remote control. This is particularly practical for using a tripod arm for high ceilings.

    The App enables live measurement on HVAC systems using the start and stop function and the saving of measurement data on a smartphone or tablet. You can use the App on site to create the measurement report, and add customer and measuring site data as well as images. You can then send your readings and reports as PDF, Excel or JSON files via the e-mail function. This means you save a considerable amount of time and increase efficiency.

    Volume flow hood with removable measuring instrument - performance overview

    The volume flow hood for HVAC systems is equipped with a measuring instrument for displaying measurement data. The device can be tilted and removed for user-friendly reading of measuring values.

    The testo 420 measuring instrument enables you to measure flow velocity, volume flow, absolute pressure, temperature and relative humidity. The automatic zeroing ensures higher accuracy for low pressures.

    All measuring values are easy to read on the large display which has an illumination function. For analyses and documentation, measurement data can be saved and measurement protocols created directly on site using the App connection. It’s easy to manage the measurement data on the PC without any additional software, via the plug & play function

    The testo 420 volume flow hood with its integrated measuring instrument was not just developed for volume flow measurement at larger ceiling outlets. The measuring instrument can also be taken off the hood and used for pressure, flow and volume flow measurements in the duct. This means you can save on the purchase of an additional measuring instrument.

    You merely have to attach a Pitot tube and connection hoses (both optional) for measurements in ducts. Timed and multi-point mean calculation, as well as the combination of the two, together with simple input of the duct geometry provide you with support for measurements in ducts.

    Particularly practical: You can connect the testo 420 volume flow hood to the testo 400 VAC multifunction instrument via Bluetooth. This gives you access to other smart functions such as the entire customer and measuring site management system via the testo 400 IAQ measuring instrument.

    testo 420 volume flow hood including measuring instrument, 610 x 610 mm hood, 5 x tension rods, USB cable, batteries, trolley and calibration protocol.

    Temperature - NTC

    Measuring range
    -20 to +60 °C
    Accuracy
    ±0,5 °C (0 to +60 °C)
    ±0,8 °C (-20 to +0 °C)
    Resolution
    0,1 °C
    Reaction time
    45 s (t₉₀)

    Humidity - Capacitive

    Measuring range
    0 to 100 %RH
    Accuracy
    ±1,0 %rF Hysterese
    ±1,8 %RH +3 % of mv (at 25 °C, 5 % to 80 %RH)
    ±0,03 %RH/K (at 0 to 60 °C )
    ±1,0 %rF/year Drift
    Resolution
    0,1 %RH

    Differential Pressure - Piezoresistive

    Measuring range
    -120 to +120 Pa
    Accuracy
    ±2 % of mv + 0,5 Pa at +22 °C, 1013 hPa
    Resolution
    0,001 Pa
    Reaction time
    1 s (t₉₀)

    Accessories

  • Accessories
    testo Smart APP
    testo Smart App with the full range of functions - available as a free download
      :
      0501 5001
    • Accessories
      Replacement Hood 360mm, 360mm
      Replacement hood (360 x 360 mm) for testo 420
        :
        0554 4200
        ZAR 5,179.35 ZAR 5,956.25
      • Accessories
        Replacement Hood 305mm, 1220mm
        Replacement hood (305 x 1220 mm) for testo 420
          :
          0554 4201
          ZAR 5,936.15 ZAR 6,826.57
        • Accessories
          Replacement Hood 610mm, 1220mm
          Replacement hood (610 x 1220 mm) for testo 420
            :
            0554 4202
            ZAR 5,936.15 ZAR 6,826.57
          • Accessories
            Tripod for testo 420
            Extendable tripod (up to 3.3 m) with wheels
              :
              0554 4209
              ZAR 9,743.80 ZAR 11,205.37
            • Additional accessories and Spare parts

            • Additional accessories and Spare parts
              Connection hose, silicone
              Connection hose, silicone - max. load capacity up to 700 hPa (mbar)
                :
                0554 0440
                ZAR 1,111.55 ZAR 1,278.28
              • Additional accessories and Spare parts
                Connection hose
                Connection hose silicone-free for differential pressure measurement, length 5 m, load up to maximum 700 hPa, (mbar)
                  :
                  0554 0453
                  ZAR 1,158.85 ZAR 1,332.68
                • Additional accessories and Spare parts
                  Staurohr
                  Stainless steel Pitot tube, length 500 mm, Ø 7 mm - for measuring flow velocity
                    :
                    0635 2045
                    ZAR 3,429.25 ZAR 3,943.64
                  • Additional accessories and Spare parts
                    Staurohr
                    Stainless steel Pitot tube, length 350 mm, Ø 7 mm - for measuring flow velocity
                      :
                      0635 2145
                      ZAR 3,027.20 ZAR 3,481.28
                    • Additional accessories and Spare parts
                      Staurohr
                      Stainless steel Pitot tube, length 1000 mm, Ø 7 mm - for measuring flow velocity
                        :
                        0635 2345
                        ZAR 8,419.40 ZAR 9,682.31
