Compact basic flue gas probe, 180 mm, Ø 6 mm, Tmax 500 °C

Order-Nr.  0600 9740

  • Flue gas path and temperature channel can be connected to the instrument via a bayonet lock

  • Integrated dirt filter protects instrument and sensors

  • Integrated thermocouple probe for temperature measurements up to 500 °C

  • Includes practical cone for attachment

Compact basic flue gas probe with 180 mm long probe shaft, integrated thermocouple and dirt filter.

Product Description

The compact basic flue gas probe is equipped with a dirt filter, which protects the measuring instrument and its sensors. Flue gas path and temperature channel can conveniently be connected to the measuring instrument via a practical bayonet lock. The thermocouple NiCr-Ni, which is integrated in the 180 mm long probe shaft, enables temperature measurement up to 500 °C.



Delivery Scope

Compact basic flue gas probe 180 mm including dirt filter, cone for attachment, thermocouple NiCr-Ni Tmax 500 °C and hose 1.5 m.
General technical data

Length probe shaft

300 mm

Cable length

1.5 m

Diameter

6 mm

Temperature maximum

500 °C
