    2. Modular flue gas probe, 300 mm, Ø 6 mm, Tmax 500°C

    Modular flue gas probe - 300 mm, Ø 6 mm, Tmax 500°

    0600 9763
    £ 247.00 £ 296.40
    1
  1. Easy probe shaft change via quick-change click system
  2. Flue gas path and temperature channel can be connected to the instrument via a bayonet lock
  3. Integrated dirt filter protects instrument and sensors
  4. Integrated thermocouple probe for temperature measurements up to 500°C
  5. Modular flue gas probe with 300 mm long probe shaft, including dirt filter and thermocouple. The quick-change click system enables quick, flexible replacement of the probe shaft.
    The modular flue gas probe with 300 mm long probe shaft features a quick-change click system on the handle, which enables really easy replacement of the probe shaft. The thermocouple NiCr-Ni, which is integrated into the probe shaft, enables temperature measurement up to 500°C. Flue gas path and temperature channel can be conveniently connected to the measuring instrument via a practical bayonet lock. In addition, a dirt filter protects the instrument and its sensors from contamination.

    Modular flue gas probe 300 mm, including dirt filter, cone for fixing, thermocouple NiCr-Ni.

    General technical data

    Diameter probe shaft
    6 mm
    Cable length
    2.2 m
    Length probe shaft
    300 mm
    Product colour
    Black
    Temperature maximum
    500 °C
    Diameter
    6 mm
    Weight
    532 g

    Accessories

  6. Accessories
    Hose extension
    Hose extension - probe-instrument extension hose (length 2.8 m)
      :
      0554 1202
      £ 193.00 £ 231.60
      1
    • Accessories
      Spare particle filter
      Spare dirt filters - for probe handle (10 off)
        :
        0554 3385
        £ 26.00 £ 31.20
        1
      • Accessories
        Cone with fixing screw
          :
          0554 9010
          £ 25.50 £ 30.60
          1
        • Accessories
          Battery Cover for testo 510 Pressure Gauge
            :
            0192 5333
            £ 2.00 £ 2.40
            1
          • Accessories
            Clear Cap for Flue Gas Analyser Probes
              :
              0192 1108
              £ 3.00 £ 3.60
              1
            • Accessories
              Cone (6mm) for Flue Gas Probe
                :
                0170 9070
                £ 11.00 £ 13.20
                1
              • Accessories
                Screw for flue gas probe
                  :
                  0170 0147
                  £ 2.00 £ 2.40
                  1
