testo 560i - Digital refrigerant scale with Bluetooth

Measuring refrigerant weight quickly, precisely and conveniently - that's only possible with the testo 560i digital refrigerant scale.

Operation and display of measured values are completely wireless using a Testo manifold and the testo Smart App. For this purpose, the scale automatically connects via Bluetooth with a manifold and a smartphone or tablet
Versatile in all situations: Bluetooth range of up to 100 ft
And best of all: with the testo 560i Intelligent Valve (available separately), you can charge refrigeration systems, ductless mini-splits, and heat pumps automatically according to target refrigerant weight, superheat, subcooling, and even Target superheat
Compatible with testo Smart Digital Manifolds (550s / 557s / 550i), testo Digital Manifolds with Bluetooth (550bt / 557bt) as well as testo Smart Probes (115i/ 549i/605i), all connecting to the testo Smart App for Android and iOS

Advantages of the testo 560i refrigerant scale

High measurement accuracy with resolution .02 lbs and output in lbs or kg
Maximum load of 220 lbs for all common refrigerant containers
High Bluetooth range of up to 100 ft
Fully automatic charging according to target value (with testo Intelligent Valve sold separately)
Safe handling: 3D corners for accurate positioning of the refrigerant container and textured rubber surface for stable grip
High robustness due to dust and splash water protection (IP44)
Especially handy thanks to compact housing, low weight, practical carrying handle and sturdy shoulder bag
Long battery life of up to 70 hours thanks to replaceable AA batteries and auto power-off function
High flexibility in outdoor use at temperatures from 14 to 122° F

Delivery Scope

General technical data	Operating humidity 0 to 80 %rH
Weight 4.36 kg (incl. batteries and bag)
Measuring range 0 to 100 kg
Accuracy +/- 0.4oz + 0.03% of rdg (0 to 66.1lbs) / ≤ ±(10 g+ 0.03 %rdg) (0 to 30 kg) Operating temperature +72 °F: / Operating temperature +22 °C: +/- 0.4oz +0.05% of rdg (66.2 to 220.4lbs) / ≤ ±(10 g+ 0.05 %rdg) (30 to 100 kg)
Resolution 0.01 kg
Dimensions 12.21 x 11.30 x 2.28 in. / 310 x 287 x 58 mm (LxWxH)
Operating temperature 14° to 122 °F / -10 to +50 °C
Protection class IP44
Battery life > 70 h at +25 °C
Battery type 4 x AA batteries
Interface Bluetooth® 4.2
Radio range 98.424 ft. / 30 m
Storage temperature 14° to 122 °F / -10 to +50 °C

Operating humidity

0 to 80 %rH

Weight

4.36 kg (incl. batteries and bag)

Measuring range

0 to 100 kg

Accuracy

+/- 0.4oz + 0.03% of rdg (0 to 66.1lbs) / ≤ ±(10 g+ 0.03 %rdg) (0 to 30 kg)

Operating temperature +72 °F: / Operating temperature +22 °C:

+/- 0.4oz +0.05% of rdg (66.2 to 220.4lbs) / ≤ ±(10 g+ 0.05 %rdg) (30 to 100 kg)

Resolution

0.01 kg
