Temperature probe with Velcro (TC Type K)

Order-Nr.  0628 0020

  • With Velcro: makes it easy to attach the surface probe to pipes with a diameter of up to 120 mm

  • TC Type K temperature probe with 1.5 m cable

  • Measuring range: -50 to +120 °C

Temperature probe with Velcro for surface measurements on pipes

Delivery time: 3 – 5 working days

Shipping costs

£ 34.90
£ 41.88 incl. VAT

Product Description

Overview

Use this temperature probe with thermocouple (TC) sensor to carry out surface temperature measurements on pipes with a pipe diameter of up to 120 mm. For example, you can use it to determine the surface temperature of heating pipes.

The TC sensor for measuring temperature is attached to a 20 mm wide, 395 mm long strip. The Velcro fastener on this strip enables the surface probe to be attached to the pipe quickly and easily.

For optimum heat transfer between the surface probe and the measurement object, we recommend using our optional silicone thermal conduction paste.

The surface probe features a 1.5 m cable.This Type K, Class 1 thermocouple probe has a standardised accuracy of ±1.5 °C.



Delivery Scope

1 x TC Type K temperature probe 0628 0020, for the testo Saveris 2-T3 Wi-Fi data logger

Temperature - TC Type K (NiCr-Ni)

Measuring range

-50 to +120 °C

Accuracy

Class 1 ¹⁾

Reaction time

90 s

1) According to standard EN 60584-2, the accuracy of Class 1 refers to -40 to +1000 °C (Type K)

General technical data

Diameter

120 mm

Temperature maximum

120 °C

Length probe shaft

395 mm

Diameter probe shaft tip

20 mm
