Air Probe - NTC

Order-Nr. 0613 1712

NTC temperature sensor
High level of accuracy of up to ±0.2 °C
Short response time thanks to the exposed sensor
Measuring range: -50 to +125 °C

NTC Air Probe with a miniDIN type connection allows you to accurately measure air temperature. Compatible with any Testo product with a miniDIN connector, the NTC Air Probe is a solution for a variety of temperature applications.

+1-484- 773 0111

Inquiry

Where to buy

Product Description

Fast, robust and easy to use: simply hold the air temperature probe in the environment being measured – and, thanks to the exposed sensor in the probe shaft, you will obtain the air temperature value after only a short response time. The measurement result can be optimized by moving the probe through the air at approx. 1.5 m/s.

Delivery Scope

Robust air temperature probe (NTC) with fixed cable 1.2 m.

Temperature - NTC
Measuring range	-58.0° to 257.0 °F / -50 to +125 °C ²⁾
Accuracy	±0.4 °F (-13° to +176 °F) / ±0.2 °C (-25 to +80 °C) ±0.7 °F (Remaining Range) / ±0.4 °C (Remaining Range)
Reaction time	60 sec

Temperature - NTC

Measuring range

-58.0° to 257.0 °F / -50 to +125 °C ²⁾

Accuracy

±0.4 °F (-13° to +176 °F) / ±0.2 °C (-25 to +80 °C)

±0.7 °F (Remaining Range) / ±0.4 °C (Remaining Range)

Reaction time

60 sec

1) Long-term measurement range +125°C, short-term +150°C or +140°C (2 minutes)

General technical data
Dimensions	49 in. / 1250 mm
Length probe shaft	4.528 in. / 115 mm
Housing	ABS / TPE / PUR
Fixed cable	yes
Cable length	3.609 ft. / 1.1 m
Diameter probe shaft tip	0.157 in. / 4 mm
Diameter probe shaft	0.197 in. / 5 mm
Length probe shaft tip	1.969 in. / 50 mm
Product colour	grey; Black; silver
Weight	3.67 oz. / 104 g
