Frozen food probe, corkscrew design - Frozen food probe

Order-Nr. 0603 3292

Can easily be screwed into frozen food, no pre-drilling required
Cable detachable
Very robust design
Thermocouple type T

Frozen food probe, corkscrew design, Tmax handle and cable +158°F

Product Description

The frozen goods probe (TC type T) is primarily used for measuring the core temperature of frozen food. Thanks to a special handle and its helical tip, it can be screwed directly into frozen food without the need for pre-drilling.

Delivery Scope

1 x frozen goods probe (TC type T) for screw-in use without pre-drilling, including plug-in cable (cable length 1.7 m).

Temperature - TC Type T (Cu-CuNi)
Measuring range	-58.0° to 662.0 °F / -50 to +350 °C
Accuracy	±0.4 °F (-4.0° to 158.0 °F) / ±0.2 °C (-20 to +70 °C) Class 1 (Remaining Range) ¹⁾
Reaction time	8 sec

Temperature - TC Type T (Cu-CuNi)

Measuring range

-58.0° to 662.0 °F / -50 to +350 °C

Accuracy

±0.4 °F (-4.0° to 158.0 °F) / ±0.2 °C (-20 to +70 °C)

Class 1 (Remaining Range) ¹⁾

Reaction time

8 sec

1) According to standard EN 60584-2, the accuracy of Class 1 refers to -40 to +350 °C (Type T).

General technical data
Dimensions	72 in. / 1840 mm
Length probe shaft	4.331 in. / 110 mm
Housing	Stainless steel / GFK
Protection class	IP65
Fixed cable	yes
Cable length	5.577 ft. / 1.7 m
Diameter probe shaft tip	0.157 in. / 4 mm
Diameter probe shaft	0.315 in. / 8 mm
Length probe shaft tip	1.181 in. / 30 mm
Product colour	white
Measuring rate	8
Weight	5 oz. / 132 g

Product Brochures

Declaration of Conformity according to Reg. (EU) 1935/2004 (application/pdf, 199 KB)

Manuals

frozen food probe 0602 3292 en,de (PDF, 224.6 kB)
