Robust air temperature probe (TC type K) - 2 channel

Order-Nr. 0602 1793

Thermocouple type K
Short response time thanks to the exposed sensor
Can be connected to a wide range of measuring instruments
Measuring range: -60 to +400 °C

Use the robust air temperature probe with exposed sensor (thermocouple type K) to measure air temperature with a short response time. It can be connected to a wide range of measuring instruments.

Shipping costs

$107.00

incl. GST $117.70

+61 3 - 41089902

Inquiry

Product Description

Fast, robust and easy to use: simply hold the air temperature probe in the environment being measured – and, thanks to the exposed sensor in the probe shaft, you will obtain the air temperature value after only a short response time. The measurement result can be optimized by moving the probe through the air at approx. 1.5 m/s.

Delivery Scope

1 x robust air temperature probe (TC type K) with fixed cable.

Temperature - TC Type K (NiCr-Ni)
Measuring range	-60 to +400 °C
Accuracy	Class 2 ¹⁾
Reaction time	200 s

1) According to standard EN 60584-2, the accuracy of Class 2 refers to -40 to +1200 °C.

General technical data
Weight	112 g
Dimensions	length: 255 mm
Length probe shaft	115 mm
Cable length	1.16 m
Diameter probe shaft tip	4 mm
Diameter probe shaft	5 mm
Length probe shaft tip	50 mm
Product colour	grey
Interface	plug thermocouple
