0602 5693

Flexible immersion measurement tip for measurements in air/e... - for measurements in air / flue gases

Immersion measurement tip, flexible, for measurements in air
Flexible immersion measurement tip for measurements in air/exhaust gases (not suitable for measurements in smelters), TC Type K -328 to 1832 °F, 39" long, Ø 0.12"
  • Particularly long measuring tip
  • Thermocouple type K
  • Flexible – for optimum alignment

Temperature - Type K TC

Measuring range
-40.0° to 1832.0 °F / -40 to +1000 °C
Accuracy
Class 1 ¹⁾
Reaction time
4 sec
1) According to standard EN 60584-1, the accuracy of Class 1 refers to -40 to +1000 °C (Type K), Class 2 to -40 to +1200 °C (Type K), Class 3 to -200 to +40 °C (Type K).

General technical data

Weight
1.91 oz. / 54 g
Dimensions
41.1 x 0.1 x 0.1 in. / 1045 x 3 x 3 mm
Diameter probe shaft tip
0.118 in. / 3 mm
Length probe shaft
39.37 in. / 1,000 mm
Product colour
silver; Black
1 x flexible immersion measuring tip (TC type K).
